Ai-IR36
Stiff Zinc Alloy Anti-Vandal Housing (500 lbs) Roof Mount/Wall/Ceiling Bracket Specifications CCD-sensor 1/3" Sony CCD, DSP HQ1 Image Sensor NTSC : 768 x 494 pixels PAL : 752 x 582 pixels Resolution 600 TVL Scanning System 2:1 interlace Minimum Illumination 0 Lux (IR LEDs on, 0.5lux/F1.6) IR Working Range up to 160 meters IR LEDs 18 pcs Auto Gain Control Automatic B.L.C Automatic Electronic Shutter Auto and up to 1/100,000 Aperture (f) 2 H Mode of H.V aperture correction Lens 18~50 mm Varifocal lens with ICR Water Resistance IP67 Operating Temperature -55˚C+50˚C Power consumption IR on : 10.6W/960 mA+-20% IR off: 3.6W/270 mA+-10% Dimensions 290x100x180mm Power Supply 12V DC/ AC 24 V,18W,750mА (Standard)
Stiff Zinc Alloy Anti-Vandal Housing (500 lbs) Roof Mount/Wall/Ceiling Bracket Specifications CCD-sensor 1/3" Sony CCD, DSP HQ1 Image Sensor NTSC : 768 x 494 pixels PAL : 752 x 582 pixels Resolution 600 TVL Scanning System 2:1 interlace Minimum Illumination 0 Lux (IR LEDs on, 0.5lux/F1.6) IR Working Range up to 160 meters IR LEDs 18 pcs Auto Gain Control Automatic B.L.C Automatic Electronic Shutter Auto and up to 1/100,000 Aperture (f) 2 H Mode of H.V aperture correction Lens 18~50 mm Varifocal lens with ICR Water Resistance IP67 Operating Temperature -55˚C+50˚C Power consumption IR on : 10.6W/960 mA+-20% IR off: 3.6W/270 mA+-10% Dimensions 290x100x180mm Power Supply 12V DC/ AC 24 V,18W,750mА (Standard)
